as days pass, things become even more technical... today I installed thethe router and home and limit switches using proximity switches for the x and y axis...
the switch lights up when it senses metal within 5mm...
and under the table are the y axis proximity switches...
we were able to do a test cuts already but until the licensed software arrives, operation is still limited.
