Grunblau Platform CNC

Re: Grunblau Platform CNC

Unread post #201 by timber715 » Fri Feb 24, 2017 3:38 pm

First time to use a 1/8" down-cut bit on the cnc...
cuts came out better than impressive imo.
was running at 100ipm (inches per minute), doc (depth of cut) 0.0625", and the bit is a 0.125" downcut spiral bit.
resulting work caame clean with very little sanding needed. Mostly due to the material and not the cut.
User avatar
timber715
Admin
Admin

Posts: 4658
Joined: Fri Feb 24, 2012 12:47 am

Share On:

Share on Facebook Facebook Share on Twitter Twitter

Re: Grunblau Platform CNC

Unread post #202 by timber715 » Thu Mar 02, 2017 10:09 pm

I made a collet holder as I find it annoying to remove each piece from its box whenever I need it and the put it back after I am done...
Now all I do is open and reach for the bit whenever I need a certain size...
User avatar
timber715
Admin
Admin

Posts: 4658
Joined: Fri Feb 24, 2012 12:47 am

Re: Grunblau Platform CNC

Unread post #203 by avmanansala » Thu Mar 02, 2017 10:26 pm

Isalang mo ulit sa cnc engrave mo naman ang mga collet sizes
Once you know the password you can go anywhere. Log In. Log Out. Leg It! Password Accepted.
User avatar
avmanansala
Sr. Member
Sr. Member

Posts: 601
Joined: Fri Oct 02, 2015 8:18 pm

Re: Grunblau Platform CNC

Unread post #204 by timber715 » Thu Mar 02, 2017 10:34 pm

avmanansala wrote:Isalang mo ulit sa cnc engrave mo naman ang mga collet sizes

Isasalang ko pero to engrave the cover... no need to engrave the sizes, ako lang naman gagamit... :lolno:
User avatar
timber715
Admin
Admin

Posts: 4658
Joined: Fri Feb 24, 2012 12:47 am

Re: Grunblau Platform CNC

Unread post #205 by joey81 » Tue Mar 07, 2017 9:50 pm

timber715 wrote:Ossie, almost 450 including shipping na.


May duties and taxes?
Rotir Tools * Bosch * Dremel * Hitachi * Dewalt * Freud * Harbor Freight * Woodpecker * Incra * Skil * Whiteside * CMT * Grizzly
User avatar
joey81
Sr. Member
Sr. Member

Posts: 2013
Joined: Mon Mar 05, 2012 12:05 pm

Re: Grunblau Platform CNC

Unread post #206 by timber715 » Wed Mar 08, 2017 12:50 am

My bad, I had rechecked my billing and it comes out to about $350 landed... Using DHL instead of fedex it arrived without hassle. AVOID FEDEX at all cost!!!
User avatar
timber715
Admin
Admin

Posts: 4658
Joined: Fri Feb 24, 2012 12:47 am

Re: Grunblau Platform CNC

Unread post #207 by timber715 » Thu Mar 09, 2017 4:47 pm

Two days ago I started making a fogless coolant system for my cnc that I can use whenever I mill aluminum.
Today I call it complete. Initially I wanted a water filter container to house my coolant (I will be using mineral oil) but the containers are so big and I do not really need to spend so much for it. So I decided to try a coke bottle and it worked fine but was still too big. I now use a calamansi concentrate bottle for the coolant :wtf:
It was the perfect size that I wanted and is free... I also made a mount for it and is located on the left side of the cnc.
the lines are 4mm o.d with a 2mm i.d.. these seem to be the prefect size since I wouldn't be needing high cfm output. Also gotten several inline regulators to control the air and coolant speeds.
then it all exits beside the spindle with a bracket made of aluminum.
I can control manually the amount of coolant and/or air individually and works perfect....
User avatar
timber715
Admin
Admin

Posts: 4658
Joined: Fri Feb 24, 2012 12:47 am

Re: Grunblau Platform CNC

Unread post #208 by joey81 » Wed Mar 15, 2017 9:54 am

timber715 wrote:Wanted to make another jig but I do not have the hardware for it... hmmmm.... so I made one out of aluminum.
Still not the perfect finish out of the cnc but with a little sanding and it comes out nice.
I would be cutting the threads for it tomorrow.....


Magandang i-anodize yan :thumbup:

Rotir Tools * Bosch * Dremel * Hitachi * Dewalt * Freud * Harbor Freight * Woodpecker * Incra * Skil * Whiteside * CMT * Grizzly
User avatar
joey81
Sr. Member
Sr. Member

Posts: 2013
Joined: Mon Mar 05, 2012 12:05 pm

Re: Grunblau Platform CNC

Unread post #209 by timber715 » Wed Mar 22, 2017 12:31 am

I am making stands for Harbeth SHL5plus again this time it will go to the (Cebu) distributor for display. On the cnc I made some name plates out of 1/8' thick brass.
User avatar
timber715
Admin
Admin

Posts: 4658
Joined: Fri Feb 24, 2012 12:47 am

Re: Grunblau Platform CNC

Unread post #210 by timber715 » Wed Mar 22, 2017 7:58 pm

My first inlay on the cnc using the correct process.
User avatar
timber715
Admin
Admin

Posts: 4658
Joined: Fri Feb 24, 2012 12:47 am
