Unread post #191 by timber715 » Sat Feb 11, 2017 1:00 am

I cut several 3/8" hole on the spoilboard to allow dowels to be pegged...
then with angled pieces of stock I use them to hold down a piece.
the items are very secure and the bit doesn't get damaged when it accidentally hits the hold downs... and did I say the cost next to nothing?
User avatar
timber715
Admin
Admin

Posts: 4659
Joined: Fri Feb 24, 2012 12:47 am

Share On:

Share on Facebook Facebook Share on Twitter Twitter

Re: Grunblau Platform CNC

Unread post #192 by timber715 » Sat Feb 11, 2017 4:15 am

So much to improve here... need better lighting and use the video camera instead of te phone. But.....
User avatar
timber715
Admin
Admin

Posts: 4659
Joined: Fri Feb 24, 2012 12:47 am

Re: Grunblau Platform CNC

Unread post #193 by timber715 » Tue Feb 14, 2017 6:08 pm

Still in the process of completing a hidden mitered finger joint...
still more work to be done to get this properly done...
User avatar
timber715
Admin
Admin

Posts: 4659
Joined: Fri Feb 24, 2012 12:47 am

Re: Grunblau Platform CNC

Unread post #194 by Violaine » Wed Feb 15, 2017 4:09 am

nakakatuwa namang utusan yan! kahit ano pede ipagawa! :clap:
I think i was a woodworker in my previous life...and the life previous to that.
User avatar
Violaine
Sr. Member
Sr. Member

Posts: 2986
Joined: Sat Mar 03, 2012 10:06 pm

Re: Grunblau Platform CNC

Unread post #195 by timber715 » Fri Feb 17, 2017 9:32 pm

Wanted to make another jig but I do not have the hardware for it... hmmmm.... so I made one out of aluminum.
Still not the perfect finish out of the cnc but with a little sanding and it comes out nice.
I would be cutting the threads for it tomorrow.....
User avatar
timber715
Admin
Admin

Posts: 4659
Joined: Fri Feb 24, 2012 12:47 am

Re: Grunblau Platform CNC

Unread post #196 by bugel » Sat Feb 18, 2017 2:03 am

Wow! Ang galeng naman! :clap:
User avatar
bugel
Sr. Member
Sr. Member

Posts: 1135
Joined: Tue Aug 20, 2013 8:13 pm

Re: Grunblau Platform CNC

Unread post #197 by timber715 » Sat Feb 18, 2017 2:07 am

bugel wrote:Wow! Ang galeng naman! :clap:

baba kang Manila kung may time sa Feb26 brad...
User avatar
timber715
Admin
Admin

Posts: 4659
Joined: Fri Feb 24, 2012 12:47 am

Re: Grunblau Platform CNC

Unread post #198 by timber715 » Tue Feb 21, 2017 2:18 am

went back and made a thinner geared screw this time on brass and slightly smaller too...
measures 0.25 x 0.6" and is threaded with an M4 sized thread...
came out straight from the cnc without cleaning or sanding...
User avatar
timber715
Admin
Admin

Posts: 4659
Joined: Fri Feb 24, 2012 12:47 am

Re: Grunblau Platform CNC

Unread post #199 by timber715 » Tue Feb 21, 2017 4:51 pm

Now I do like cutting simple stickers on my cnc. So why not make a dedicated cutting platform for it.
I decided on using phenolic as the base board for it.
it has four holes cut to fit on my spoiler board using dowels. Then I sprayed adhesive on the cutting mat and mounted it...
User avatar
timber715
Admin
Admin

Posts: 4659
Joined: Fri Feb 24, 2012 12:47 am

Re: Grunblau Platform CNC

Unread post #200 by timber715 » Thu Feb 23, 2017 2:50 pm

Tested my spidle when I got it and now tested it again for runout after weeks of use...

I think I did good on this purchase... :lolno:
User avatar
timber715
Admin
Admin

Posts: 4659
Joined: Fri Feb 24, 2012 12:47 am
